ROTOR DISC » RN1003

Specification

Type
Solid
Disc Thickness (Max)
10.8
Num. of holes
4
Height
44
Centering Diameter
66
Front/Rear
Rear
Pitch Circle Ø
100
Outter Ø
265
Drum Ø:
149
Disc Thickness (Min)
9.5
Structure Material
G3000

Cross Reference

BENDIX
561595B
OEM
34300327RP
RENAULT
7700800002
RENAULT
7701201295
RENAULT
7701204295
RENAULT
7701205844
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
01.92~10.96 2000 J7R7 B540 PN0249W RN1003 PN0282
06.92~07.96 2100 J8S760 B546 PN0249W RN1003 PN0282FN9690
01.92~02.99 2200 G8T740 B541 PN0249W RN1003 PN0282
06.92~07.96 2200 G8T740 B543 PN0249W RN1003 PN0282
01.92~02.99 2200 G8T740 B54G PN0249W RN1003 PN0282
06.92~07.96 2200 J7T76# B541 PN0249W RN1003 FN9690PN0282
06.92~07.96 2200 J7T76# B543 PN0249W RN1003 PN0282
01.92~02.99 2200 J7T76# B54G PN0249W RN1003 PN0282

Exemption from liability: the catalog data is advisory and can be used for reference only
