ROTOR DISC » RN1068V
Specification
Type
Vented
Disc Thickness (Max)
22
Num. of holes
4
Height
40.3
Centering Diameter
59
Front/Rear
Front
Pitch Circle Ø
98
Outter Ø
257.2
Drum Ø:
125
Disc Thickness (Min)
20
Structure Material
G3000
Hole Ø:
13
Cross Reference
ALFA ROMEO
46401356
ALFA ROMEO
46831041
BENDIX
562178B
CHRYSLER
05154237AA
CHRYSLER
K05154237AA
CITROEN
4249 74
FIAT
46401356
FIAT
46542383
FIAT
46831041
FIAT
5 189 6288
FIAT
51896287
FIAT
52063172
FIAT
71739640
Peugeot / Citroen
4249 E5
Peugeot / Citroen
4249 L2
Peugeot / Citroen
4249.73
| years | Eng | Eng No | Body | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 08.08~06.11 | 1400 | 199.A8.000 | 955 | RN1068V | PN0211W | RN1869 | PN0515 | |
| 08.08~08.13 | 1400 | 955 A1.000 | 955 | RN1068V | PN0209W | RN1869 | PN0515 |
| 01.08~ | 1400 | 1.4 HDi 70 | Minivan | RN1068V | PN0211W | DN1562 | FN0624 | |
| 01.08~ | 1400 | DV4T | RN1068V | PN0211W | DN1562 | FN0624FN0682 |
| 01.07~01.12 | 1400 | 169 A3.000 | 150.045.0.5 | RN1068V | PN0211W | RN1385 | PN0197 | |
| 12.10~08.17 | 1400 | EAB | FF | RN1068V | PN0631W | RN1385 | PN41003 |
| 10.05~06.10 | 1300 | 199 A2.000 | 223.317.2.0 | RN1068VRN2026V | PN0211WPN0187 | DN1697 | FN41002 | |
| 01.05~01.16 | 1900 | 223 B1.000 | 223.313.2.0 | RN2026VRN1068V | PN0187PN0211W | DN1697 | FN41002 |
| 01.07~01.16 | 1300 | 199 A2.000 | 2252L2051870 | RN1068V | PN0211W | DN1697 | FN0624 | |
| 05.14~ | 1400 | 327 A.011 | 87CV | RN1068V | PN0211W | FN0624 | ||
| 10.09~ | 1400 | 350 A1.000 | LCVs | RN1068V | PN0211W | DN1711 | FN0682 | |
| 01.08~ | 1400 | KFT | LCVs | RN1068V | PN0211W | DN1711 | FN0682 |
| 01.03~ | 1200 | RN1068V | PN0211W | |||||
| 01.03~ | 1300 | RN1068V | PN0211W | |||||
| 01.03~01.08 | 1400 | 843 A1.000 | 135.512.0.0 | RN1068V | PN0211W | DN1711 | FN0682 | |
| 01.03~ | 1900 | RN1068V | PN0187W | DN1697 |
| 02.12~ | 900 | 312 A# | 312 | RN1068V | PN41005 | RN1385 | FN0682PN41003 | |
| 09.03~08.13 | 1100 | 187 A1.000 | 169A | RN1068V | PN0287WPN0211W | DN1711DN1710RN1385 | FN0586FN0616FN0774FN0682PN0192 | |
| 03.10~08.13 | 1200 | 169 A4.000 | 169A | RN1068V | PN0287WPN0211W | RN1385DN1710DN1711 | FN0682PN0192FN0586FN0774FN0616 | |
| 12.03~12.06 | 1300 | 188 A9.000 | 169A | RN1068V | PN0287WPN0211W | RN1385DN1710DN1711 | FN0774FN0586FN0682FN0616PN0192 | |
| 02.12~ | 1300 | 199 A9.000 | 312 | RN1068V | PN41005 | RN1385 | PN41003 | |
| 10.06~08.13 | 1400 | 169 A3.000 | 169A | RN1068V | PN0287WPN0211W | DN1710DN1711RN1385 | FN0586FN0616FN0774PN0192FN0682 |
| 01.08~ | 1300 | RN1068V | PN0211W | FN0624 | ||||
| 01.08~ | 1400 | KFT | 255 | RN1068V | PN0211W | FN0624 | ||
| 01.09~ | 1400 | KFV | 255 | RN1068V | PN0211W | FN0682 | ||
| 01.07~01.16 | 1400 | KFV | 3002P1051870 | RN1068V | PN0211W | DN1711 | FN0682 |
| 10.01~10.03 | 1200 | 188 A5.000 | 192AXA1B | RN1068V | PN0211W | PN0515 | ||
| 10.01~10.03 | 1200 | 188 A5.000 | 192BXA1B | RN1068V | PN0211W | PN0515 | ||
| 08.03~ | 1400 | 843 A1.000 | 192AXH1B | RN1068V | PN0211W | PN0515 | ||
| 08.03~ | 1400 | 843 A1.000 | 192BXH1B | RN1068V | PN0211W | PN0515 | ||
| 08.03~ | 1400 | 843 A1.000 | 192CXH1B | RN1068V | PN0187W | PN0515 | ||
| 10.01~08.02 | 1600 | 182 B6.000 | 192AXB1 | RN1068V | PN0211W | PN0515 | ||
| 10.01~08.02 | 1600 | 182 B6.000 | 192BXB1 | RN1068V | PN0211W | PN0515 | ||
| 09.02~ | 1600 | 182 B6.000 | 192CXB1A | RN1068V | PN0187W | PN0515 | ||
| 10.01~08.02 | 1800 | 192 A4.000 | 192A | RN1068V | PN0187W | PN0515 | ||
| 10.01~08.02 | 1800 | 192 A4.000 | 192B | RN1068V | PN0187W | PN0515 | ||
| 10.01~08.02 | 1800 | 192 A4.000 | 192C | RN1068V | PN0187W | PN0515 | ||
| 10.01~08.02 | 1800 | 192 A4.000 | 192XC1 | RN1068V | PN0187W | PN0515 |
