ROTOR DISC » RN1175

Specification

Type
Solid
Disc Thickness (Max)
10
Num. of holes
4
Height
61
Centering Diameter
76
Front/Rear
Rear
Pitch Circle Ø
114.3
Outter Ø
262
Drum Ø:
168

Cross Reference

HYUNDAI
58411-38310
KIA
584113C000
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
03.98~02.01 2000 G4JP EF RN1231V PN2245PN0377 RN1175 FN0612
02.01~06.06 2000 G4JP EF RN1230V PN2245PN0377 RN1175 PN0436PN0539
03.98~02.01 2500 G6BV EF RN1230V PN2245 RN1175 PN0539
01.00~10.05 2000 G4JP GD RN1230V PN2245 RN1175 PN0539
01.00~10.05 2500 G6BV GG RN1230V PN2245 RN1175 PN0539FN0612
01.00~10.05 2000 G4JP FS RN1230V PN2245 RN1175 PN0539
01.00~10.05 2500 G6BV FS RN1230V PN2245 RN1175 PN0539FN0612

Exemption from liability: the catalog data is advisory and can be used for reference only
