ROTOR DISC » RN1190

Specification

Type
Solid
Disc Thickness (Max)
9
Num. of holes
4
Height
55.5
Centering Diameter
55
Front/Rear
Rear
Outter Ø
258
Pitch Circle Ø
100
Drum Ø:
172
Disc Thickness (Min)
8
Structure Material
G3000

Cross Reference

TOYOTA
42431-02090
TOYOTA
42431-02120
TOYOTA
4243102070
TOYOTA
4243102071
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
01.01~02.07 1400 4ZZ-FE ZZE120L RN1198V PN1472PN1224 RN1190RN1308 PN1827PN1454 FN0648
03.01~08.08 1600 3ZZ-FE ZZE121L RN1198V PN1472PN1224 RN1190 PN1827PN1454 FN0614
05.07~07.08 1800 1ZZ-FBE ZZE122L RN1198V PN1224 RN1190 PN1827 FN0614
05.07~07.08 1800 1ZZ-FE ZZE122 RN1198V PN1472 RN1308RN1190 PN1454 FN0614
05.02~07.08 1800 1ZZ-FE ZZE122L RN1198V PN1224 RN1190 PN1827 FN0614
11.01~02.07 1600 3ZZ-FE ZZE121L RN1198V PN1224 RN1190 PN1827 FN0648
11.01~02.07 1600 3ZZ-FE ZZE121R RN1198V PN1224 RN1190 PN1827 FN0648

Exemption from liability: the catalog data is advisory and can be used for reference only
