ROTOR DISC » RN1253V

Specification

Type
Vented
Disc Thickness (Max)
18
Num. of holes
4
Height
46
Centering Diameter
55
Front/Rear
Front
Pitch Circle Ø
100
Outter Ø
234.8
Drum Ø:
124.3
Hole Ø:
13.2
Disc Thickness (Min)
16

Cross Reference

MAZDA
B25Y3325XB
MAZDA
B458-33-25XA
MAZDA
B458-33-25XB
MAZDA
B4583325XD
MAZDA
B5Y23325XC
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
12.99~07.02 1300 B3-E DW3W RN1253V PN5232 FN3388
08.96~12.99 1300 B3-ME DW3W RN1253V PN5232 FN3387FN3388
01.00~12.04 1500 B5-E DW RN1315VRN1253V PN5232 FN3388
12.99~07.02 1500 B5-E DW5W RN1253V PN5232 FN3388
08.96~12.99 1500 B5-ME DW5W RN1253V PN5232 FN3388FN3387
04.98~11.03 1300 B3 BJ3P RN1253V PN5425 FN3394
04.98~11.03 1500 ZL BJ5P RN1253V PN5425 FN3394
04.98~11.03 1500 ZL BJ5W RN1253V PN5425 FN3394

Exemption from liability: the catalog data is advisory and can be used for reference only
