ROTOR DISC » RN1316V
Specification
Type
Vented
Disc Thickness (Max)
29.5
Num. of holes
5
Height
55.6
Centering Diameter
76
Front/Rear
Front
Pitch Circle Ø
120
Outter Ø
308
Drum Ø:
155
Disc Thickness (Min)
27
Structure Material
G3000
Cross Reference
BENDIX
562234B
VAG
7E0 615 301 D
VAG
7H0 615 301 D
VAG
JZW 615 301 E
| years | Eng | Eng No | Body | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 01.03~11.06 | 2500 | BAC | 7LAAA_ | RN1316V | PN0353W | RN2499V | PN0611W | FN0589 |
| 07.03~11.06 | 2500 | BLK | 7LAA__ | RN1316V | PN0345PN0353W | PN0611WPN0347W | FN0589 | |
| 01.06~05.10 | 2500 | BPE | 7L____ | RN1316V | PN0353W | RN2499V | PN0611W | FN0589 |
| 05.04~11.06 | 3200 | BMV | 7LA___ | RN1745VSETRN1235VRRN1745VLRN1316VRN1745VRRN1235VL | PN0346WPN0345PN0486PN0353W | RN2499VRN1737V | PN0611WPN0347WPN0541W | FN0589FN0638 |
| 05.04~05.06 | 3200 | BRJ | 7LA_G_ | RN1316V | PN0353W | RN2499V | PN0611W | |
| 09.07~04.10 | 4200 | RN1316V | PN0529 | PN0530 | ||||
| 08.02~11.06 | 5000 | AYH | 7LA_H1 | RN1316V | PN0346SPN0346WPN0346WS | PN0347W | ||
| 02.02~12.09 | 5000 | BPH | 7L | RN1316V | PN0346WPN0346WSPN0346S | PN0347W |
| 04.03~12.09 | 1900 | AXB | 7H_142 | RN1316V | PN0353W | RN1399V | PN0330W | |
| 01.06~12.09 | 1900 | BRS | T5 | RN1740VRN1316V | PN0353W | RN1399VRN2499V | PN0330WPN0611W | FN0589 |
| 09.09~08.15 | 2000 | CAAB | 7E_122 | RN1316V | PN0353W | RN1399V | PN0330W | |
| 04.15~ | 2000 | CJK# | T6 | RN1740VRN1316V | PN0353WPN33001W | RN2499VRN1399V | PN0611WPN0330W | FN0589 |
| 10.19~ | 2000 | CXGD | 7H_ | RN1316V | PN33015W | RN1399V | PN0330W | |
| 04.15~12.19 | 2000 | CXHA | SGA_ | RN1316V | PN0353W | RN1399V | PN0330W | |
| 07.19~ | 2000 | CXHA | SHA_ | RN1316V | PN33015W | RN1399V | PN0330W |
