NiBK » BRAKE SHOE » FN11158

Specification

Radius
101.6
Width
38
Thickness
3.2
Pcs In Set
4

Cross reference

HYUNDAI
58305-171700
HYUNDAI
58305-17A00
HYUNDAI
58305-28A00
HYUNDAI
58305-28B00
HYUNDAI
58305-28C00
HYUNDAI
58305-28E00
HYUNDAI
58305-29A00
HYUNDAI
58305-29A10
HYUNDAI
58305-29A70
Years Eng Eng No Body Front rotor Front Brake Rear Rotor Rear Brake Parking Shoe
01.04~01.05 1500 G4EB LC PN0091 FN11158
01.05~ 1500 G4EC-G MC PN0091 FN11158
01.00~12.06 1500 G4EC XD PN0542PN2245 FN11158PN2130FN11162
06.00~07.03 1800 G4BB XD PN2245 FN11158PN2130
06.95~05.00 1800 G4GM JF2 PN2245 PN2130FN11158
06.97~05.03 2000 G4DF J2 PN2245 PN2130FN11158
06.00~10.07 2000 G4GC XD PN2245 PN2130FN11158
11.96~01.02 1600 G4GR PN2245 PN2130FN11158
04.96~12.01 2000 JG PN2245 PN2130FN11158
06.00~03.06 1500 G4EB XD PN2245 FN11158PN2130
05.00~03.06 1600 G4ED XD FN11158
06.00~03.06 1600 G4ED-G XD RN1230V PN2245PN0788PN0377 RN1130 PN2130 FN11158
06.00~03.06 1800 G4BB XD PN2245 PN2130FN11158
04.00~03.06 2000 G4GC XD RN1230V PN3271PN0788PN2245 RN1130 PN2130FN11158
01.90~05.95 1600 J1 RN1230V PN0788PN0419 RN1130 PN2130FN11158
01.90~05.95 1800 G4GM J1 PN2245PN2176 FN11158PN2130
06.95~05.01 1600 G4ED J2 PN2245 FN11158PN2130
05.95~05.01 1600 G4GR J2 PN2245PN0091 PN2130FN11158
06.97~05.00 2000 G4DF J2 PN0091PN2245 PN2130FN11158
12.90~05.95 1500 G15B JF3J PN0091 FN11158
12.90~05.95 1500 G4DJ JF3J PN0091 FN11158
02.97~05.00 1500 G4EK J2 RN1007V PN2245 PN2130FN11158
09.95~05.00 1800 G4GM JF3M PN2245 RN1130 FN11158PN2130
04.97~05.00 1900 2DN J2 RN1007V PN2245 PN2130FN11158
04.97~05.00 2000 G4DF JF3F PN2245 PN2130FN11158
08.01~12.08 1500 D3EA PM8 PN2245 FN11158
08.01~12.08 1500 D3EA PN81 PN2245 FN11158
06.01~12.08 1600 G4ED PM8 PN2245 FN11158
06.01~12.08 1600 G4ED PN81 RN1230V PN0788 FN11158
01.01~12.08 1800 RN1230V PN2245PN0788 PN0539FN11158
12.01~12.08 1800 G4GB PM8 RN1230V PN2245 FN11158
12.01~12.08 1800 G4GB PN81 RN1230V PN0788 FN11158

Exemption from liability: the catalog data is advisory and can be used for reference only.
