ROTOR DISC » RN1930V

Specification

Type
Vented
Outter Ø
320
Num. of holes
5
Disc Thickness (Max)
20
Height
43
Centering Diameter
63.6
Pitch Circle Ø
108
Drum Ø:
141
Disc Thickness (Min)
17.5
Structure Material
G3000
Notes

Cross Reference

VOLVO
31400778
VOLVO
31471816
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
03.16~ 2000 B 4204 T23 234 RN2258V PN0747 RN1930V PN0650
03.16~ 2000 B 4204 T27 SDN RHD RN1952VRN2258V PN0747PN0696 RN2334RN1930V PN0650PN0892
03.16~ 2000 B4204 T23 LF RN1984VRN1952V PN0696 RN1930V PN0650
01.15~ 2000 B4204T27 LF RN1984VRN1952V PN0696 RN1930VRN1953V PN0650
03.16~ 2000 D4204T11 LF RN1984VRN1952V PN0696 RN1930VRN1953V PN0650
01.15~ 2000 D4204T14 D4 RN1952VRN1984V PN0696 RN1953VRN1930V PN0650
05.16~ 2000 D4204T23 D5 RN1952VRN1984V PN0696 RN1930VRN1953V PN0650

Exemption from liability: the catalog data is advisory and can be used for reference only
