ROTOR DISC » RN1949

Specification

Type
Solid
Outter Ø
279
Num. of holes
5
Disc Thickness (Max)
10
Height
30.4
Centering Diameter
62
Pitch Circle Ø
114.3
Drum Ø:
155.5
Disc Thickness (Min)
8.5
Structure Material
G3000

Cross Reference

GM
19184535
TOYOTA
42431-02210
TOYOTA
42431-12290
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
01.08~12.10 2400 LAX(2AZFE) SL26 RN1241V PN1530 RN1949 PN1519
12.06~04.12 2400 2AZ-FE AZE154H RN1434V PN1524 RN1949 PN1519
12.06~04.12 2400 2AZ-FE AZE156H RN1434V PN1524 RN1949 PN1519
08.07~04.12 3500 2GR-FE GRE156H RN1241V PN1530 RN1949 PN1519
01.08~01.13 2400 2AZ-FE AZE141 RN1241V PN1530 RN1949 PN1519
06.15~05.18 1800 2ZR-AE ZRE186L RN1241V PN1530 RN1949 PN1519
03.10~12.15 2400 2AZ-FE AZE151 RN1434V PN1524 RN1949 PN1519

Exemption from liability: the catalog data is advisory and can be used for reference only
