NiBK » PERFORMANCE ROTOR DISC » RN1348DSET

Specification

Type 1:
Direction Vented
Outter Ø
300
Num. of holes
5
Disc Thickness (Max)
28
Disc Thickness (Min)
26
Height
47.8
Centering Diameter
69
Pitch Circle Ø
114.3
Drum Ø:
143

Cross reference

HYUNDAI
51712-0Z000
HYUNDAI
51712-1M500
HYUNDAI
51712-2Y000
HYUNDAI
51712-3K100
HYUNDAI
51712-3K110
HYUNDAI
51712-3K150
HYUNDAI
51712-3K160
HYUNDAI
51712-M0500
HYUNDAI
517123K300
Years Eng Eng No Body Front rotor Front Brake Rear Rotor Rear Brake Parking Shoe
08.16~ 2000 G4NA M017 RN1348V PN0373 PN0436
01.11~12.15 1700 D4FD DF RN1348V PN0052 RN1556 PN0538
09.11~ 2000 G4NC LC81 RN1348V PN0052 RN1556 PN0538
01.14~ 1600 1600 CC - GAMMA WAGON - 5DR 5P RN1348V PN0052 RN1307 PN0436 FN11006
03.10~ 2000 10MY RN1348V PN0052 RN1176 PN0436 FN11008
10.09~08.13 2000 D4HA TM10 RN1348V PN0052 RN1176 PN0436 FN11006
01.10~08.13 2000 D4HA TMZ10 RN1348V PN0052 RN1176 PN0436 FN11009
07.13~06.15 2000 D4HA TMZ14 RN1348V PN0052 RN1176 PN0436 FN11009
11.09~ 2000 G4KD LM RN1348V PN0052 RN1176 PN0436 FN11009
11.09~08.13 2000 G4KD TM10 RN1348V PN0052 RN1307 PN0436 FN11006
01.10~08.13 2000 G4KD TMZ10 RN1348V PN0052 RN1176 PN0436 FN11009
07.13~06.15 2000 G4NA TMZ14 RN1348V PN0052 RN1307 PN0436 FN11006
02.06~ 2000 D4EA NF RN1348V PN0377 RN1476 PN0538PN0539 FN11004
01.08~ 3300 G6DB NF RN1348V PN0377 PN0539 FN11004
11.09~08.13 2000 G4KD TM10 RN1348V PN0052 RN1307 PN0436 FN11006
10.09~08.13 2400 G4KE TM10 RN1348V PN0052 RN1176 PN0436 FN11009
08.13~06.15 2400 G4KE TM14 RN1348V PN0052 RN1176 PN0436 FN11009
12.12~08.16 1700 D4FD WAGON - 5DR 7P RN1348V PN0537PN0799 RN1947 PN0538
01.15~ 2000 G4NC HU RN1348V PN0799 RN1947 PN0538
08.16~ 1700 D4FD WAGON - 5DR 7P RN1348V PN0537 RN1947 PN0538
01.13~ 1600 G4FJ FZ61 RN1348V PN0739 RN1549 PN0538
10.15~ 2000 JF RN1348V PN0536 RN1601 PN0538
01.13~12.17 1700 D4FD HU81 RN1348V RN1947 PN0538
07.11~ 2400 G4KE SL RN1348V PN0052 RN1307 PN0436 FN11008

Exemption from liability: the catalog data is advisory and can be used for reference only.
