ROTOR DISC » RN2093V

Specification

Type
Vented
Outter Ø
390
Num. of holes
5
Disc Thickness (Max)
36
Disc Thickness (Min)
34
Height
52.4
Centering Diameter
68
Pitch Circle Ø
112
Structure Material
G3000

Cross Reference

VAG
4G0 615 301 AH
VAG
4G0 615 301 E
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
01.13~12.14 4000 CRDB 4G5RRA RN2093V PN31012 PN0478W
10.14~09.18 4000 CWUB 4GDRAA RN2093V PN31012 PN0478W

Exemption from liability: the catalog data is advisory and can be used for reference only
