MOTORCYCLE BRAKE PADS » PM066

Specification

Length-1
74.7
Width-1
55.5
Thick-1
7.2
TYP
R

Cross Reference

HARLEY DAVIDSON
42739 08
HONDA
06435 MEJ 006
HONDA
06435 MEJ 016
HONDA
06455 MAS E01
HONDA
06455 MBW 006
HONDA
06455 MBW E11
HONDA
06455 MBW E12
HONDA
06455 MCF 006
HONDA
06455 MCF 016
years Eng Eng No BodyBody Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
01.08~01.10 1200 PM066 PM224
01.10~ 1200 PM066 PM224
01.02~01.02 1300 PM066 PM135
01.03~01.04 1300 PM066 PM084
01.05~01.09 1300 PM066 PM084
01.04~01.05 400 PM066 PM084
01.05~01.05 400 PM066 PM084
01.99~01.02 400 NC23 NC39 (SF) PM066 PM135
01.03~01.08 400 NC23 NC39 (SF) PM066 PM084
01.06~ 400 NC42 JH2(Revo) PM066 PM084
01.99~01.00 600 PM066 PM084
01.03~01.04 600 PM066 PM084
01.03~01.07 600 PM066 PM084PM044
01.01~01.02 600 PC35E PM066 PM084
01.98~01.99 900 PM066 PM084
01.00~01.01 900 PM066 PM084
01.02~01.03 900 PM066 PM084
01.00~01.01 1000 PM066 PM084
01.02~01.07 1000 PM066 PM084
01.12~ 125 PM066 PM006
01.09~ 650 PM066 PM174
01.10~ 700 PM066 PM174
01.11~ 700 PM066

Exemption from liability: the catalog data is advisory and can be used for reference only
