ROTOR DISC » RN1007V

Specification

Type
Vented
Disc Thickness (Max)
22
Num. of holes
4
Height
34
Centering Diameter
86
Front/Rear
Front
Pitch Circle Ø
104
Outter Ø
257
Drum Ø:
160
Disc Thickness (Min)
20

Cross Reference

BENDIX
561642B
BENDIX EUR
561642B
HYUNDAI
5171228300
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
01.96~01.02 1600 G4GR RN1007V PN2245 RN1130 PN2130
01.96~01.02 1800 RD RN1007VRN1230V PN2176 RN1130 PN2130
01.96~01.02 2000 G4GF FX RN1007V PN2245 RN1130 PN2130
05.95~05.01 1600 G4GR J2 RN1007V PN0091PN2245 RN1130 FN11158PN2130
02.97~05.00 1500 G4EK J2 RN1007V PN2245 PN2130FN11158
04.97~05.00 1900 2DN J2 RN1007V PN2245 PN2130FN11158

Exemption from liability: the catalog data is advisory and can be used for reference only
