ROTOR DISC » RN1064V

Specification

Type
Vented
Disc Thickness (Max)
18
Num. of holes
4
Height
45
Centering Diameter
55
Front/Rear
Front
Pitch Circle Ø
100
Outter Ø
235
Drum Ø:
124
Hole Ø:
13
Disc Thickness (Min)
16.5

Cross Reference

BENDIX
561871B
MAZDA
NA013325A
MAZDA
NA013325X
MAZDA
NA013325XC
MAZDA
NA013325XD
MAZDA
NAO13325XA
MAZDA
SA013325X
OEM
B4583325XD
OEM
B5Y23325XC
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
09.05~03.12 2500 N52B25A E90 (MUE) RN1064VRN1398V PN0518 RN1543V PN0511 FN0559
01.06~01.11 2500 N52B25A E93 RN1398VRN1064V PN0518 RN1306 PN0511PN0511W FN0560
09.07~10.09 2000 N47D20A E60 RN1381VRN1064V PN0518 RN1640V PN0093 FN0589
01.02~01.10 E60 RN1064V
01.02~01.10 E61 RN1064V
09.07~12.10 2000 N46B20B E60 RN1064VRN1397V PN0513 RN1640V PN0093 FN0589
06.03~03.10 2200 N54B22 E60 RN1064VRN1381V PN0513PN0518 RN1640V PN0093 FN0589
04.05~02.08 2500 N52B25A E60 RN1064V PN0513PN0222W RN1640V PN0093 FN0589
07.04~02.07 2500 N52B25A E60 RN1381VRN1064V PN0222WPN0518 RN1640V PN0093 FN0589
09.06~09.11 2500 N52B25A E60 (MUE) RN1381VRN1064V PN0222W RN1640V PN0093 FN0589
04.05~02.07 3000 N52B30A E60 RN1064VRN1381V PN0518 RN1246VRN1640V PN0093PN0326 FN0589
02.07~02.09 3000 N52B30A E60 (MUE) RN1381VRN1064V PN0518 RN1246VRN1640V PN0093PN0326 FN0589
11.06~01.10 3000 N52B30A E63 RN1381VRN1064V PN0518PN0222W RN1640V PN0093 FN0589
03.07~01.10 3000 N52B30A E63 (MUE) RN1381VRN1064V PN0518 RN1640V PN0093 FN0589
04.04~01.08 3000 N52B30A E64 RN1381VRN1064V PN0518 RN1640V PN0093 FN0589
01.03~01.10 3000 N52B30A E64 (MUE) RN1064VRN1381V PN0518 RN1640V PN0093 FN0589
01.03~01.10 E63 RN1064V
01.03~01.10 E63 RN1064V
01.03~01.10 E63 RN1064V
01.03~01.10 E64 RN1064V
10.03~10.10 4400 N62B44 E63 RN1064V PN0222PN0518 RN1246V PN0326 FN0589
10.03~10.10 4400 N62B44 E64 RN1064V PN0518PN0222 RN1246V PN0326 FN0589
01.03~01.10 E63 RN1064V
01.03~01.10 E64 RN1064V
09.05~ 4800 N62B48 E64 RN1064VRN1967V PN0518PN0222PN0655 RN1246V PN0326 FN0589
09.04~08.10 5000 S85B50A E60 (M5) RN1064V PN0655 PN0326 FN0589
06.00~11.06 3000 M54B30 E53 RN1064VRN1154V PN0401 RN1155 PN0225 FN0589
03.00~10.03 4400 M62B44 E53 RN1064VRN1154V PN0401 RN1922V PN0225 FN0589
07.03~11.06 4400 N62B44 E53 RN1154VRN1064V PN0401 RN1922V PN0225 FN0589
01.99~11.06 4600 M62B46 E53 RN1064V PN0336 PN0225
04.94~07.98 1300 B3 BA1 RN1064V PN5232 FN3385
01.88~09.93 1300 B3 BW RN1064V PN5232 FN3358FN3385
04.94~07.98 1500 Z5-DE BA1 RN1064V PN5232 PN5365FN3385
06.89~05.94 1600 B6 BG RN1064VRN1315V PN5232 FN3373FN3385
06.89~05.94 1700 PN BG RN1064V PN5232 FN3385
06.89~05.94 1800 BP BG RN1064VRN1315V PN5232PN5230 FN3385PN5198
01.89~01.98 1600 B6 NA RN1064V PN5364PN5253 PN5365PN5198

Exemption from liability: the catalog data is advisory and can be used for reference only
