ROTOR DISC » RN2122V

Specification

Type
Solid
Disc Thickness (Max)
22
Num. of holes
4
Height
45.2
Centering Diameter
61
Front/Rear
Front
Pitch Circle Ø
100
Outter Ø
237.6
Drum Ø:
125
Disc Thickness (Min)
20
Structure Material
G3000

Cross Reference

MAZDA
1N09-33-251
NISSAN
40206-WD200
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
05.99~01.07 1300 QG13DE VY11 RN2122V PN2435 FN1170
05.99~01.07 1500 QG15DE VFY11(MZ) RN2122V PN2435 FN1170FN1198
06.99~10.03 2200 YD22DD VEY11 RN2122V PN2435 FN1170
05.99~10.05 1300 QG13DE VY11 RN2122V PN2435 FN1170FN1198
05.99~10.05 1500 QG15DE VFY11 RN2122V PN2435 FN1198FN1170
05.99~12.05 1500 QG15DE WFY11 RN2122VRN1039V PN2435 FN1198FN1170

Exemption from liability: the catalog data is advisory and can be used for reference only
