ROTOR DISC » RN2164V

Specification

Type
Vented
Outter Ø
350
Num. of holes
5
Disc Thickness (Max)
32
Disc Thickness (Min)
30
Height
48.2
Centering Diameter
63.5
Pitch Circle Ø
108
Structure Material
G3000
Drum Ø:
158.5
Front/Rear
Front

Cross Reference

JAGUAR
T4A2343
JAGUAR
T4K5014
JAGUAR
T4N 1803
LAND ROVER
LR090685
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
06.17~ 2000 AJ20P4 (300PS) X761 RN2164V PN0724 RN2344V PN0650
09.15~ 3000 306DT X761 RN2164VRN2177V PN0652PN0724 RN2344V PN0650
09.15~ 3000 AJ126 X761 RN2164VRN2177V PN0724PN0652 RN2344V PN0650
08.18~ 5000 AJ133S/508PS X761 RN2164VRN2177V PN31033PN0724PN0652 RN2344V PN46001PN0650
01.18~ 400 Dual Motor 4WD X590 RN2164V PN0724 RN2344V
09.14~04.21 3000 AJ126 X760 RN2164V PN0724 RN2362V PN0650
03.17~ 3000 306DT L560 RN2164V PN0724 RN2344V PN0650
03.17~ 3000 306PS/AJ126 380PH L560 RN2164V PN0724 RN2344V PN0650

Exemption from liability: the catalog data is advisory and can be used for reference only
