ROTOR DISC » RN1765V
Specification
Type
Vented
Front/Rear
Rear
Outter Ø
302
Num. of holes
5
Disc Thickness (Max)
22
Height
40.8
Centering Diameter
63.5
Pitch Circle Ø
108
Drum Ø:
164
Structure Material
G3000
Disc Thickness (Min)
20
Cross Reference
VOLVO
30736316
VOLVO
30769060
VOLVO
31341483
VOLVO
31471028
| years | Eng | Eng No | Body | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 11.11~ | 1500 | B4154T5 | FS | RN1904VRN1756VRN1589V | PN0462WPN0483 | RN1770RN1765V | PN0463 | |
| 11.10~ | 1600 | B4164T | FS | RN1589VRN1904VRN1756V | PN0483PN0462W | RN1770RN1765V | PN0463 | |
| 11.11~12.15 | 1600 | D4162T | FS | RN1756VRN1589V | PN0483PN0462W | RN1765VRN1770 | PN0463 | |
| 03.14~12.18 | 2000 | B4204T11 | FS | RN1756VRN1589V | PN0483PN0462W | RN1770RN1765V | PN0463 | |
| 01.10~ | 2000 | B4204T6 | FS | RN1756VRN1589V | PN0483PN0462W | RN1765V | PN0463 | |
| 01.11~ | 2000 | B4204T7 | FS | RN1756VRN1589V | PN0462WPN0483 | RN1770RN1765V | PN0463 | |
| 07.10~ | 3000 | B6304T | FS | RN1589VRN1756VRN1904V | PN0483PN0462W | RN1770RN1765V | PN0463 |
| 01.07~ | 2000 | B4204T7 | AS | RN1756VRN1904VRN1589V | PN0462WPN0483 | RN1765VRN1771 | PN0463PN0461 | |
| 01.12~12.15 | 2000 | D5204T3 | AS | RN1589VRN1756V | PN0483PN0462W | RN1765VRN1771 | PN0463PN0461 | |
| 01.07~ | 2400 | D5244T4 | RN1756V | PN0483 | RN1770RN1771RN1765V | PN0463PN0461 | ||
| 07.06~ | 2500 | B5254T10 | AS | RN1589VRN1756V | PN0462WPN0483 | RN1771RN1765V | PN0463PN0461 | |
| 07.06~ | 2500 | B5254T6 | AS | RN1589VRN1756V | PN0483PN0462W | RN1765VRN1771 | PN0463PN0461 | FN0566 |
| 01.07~ | 3000 | B6304T2 | AS | RN1589VRN1904VRN1756V | PN0462WPN0483 | RN1771RN1765V | PN0463PN0461 | |
| 01.11~ | 3000 | B6304T4 | AS | RN1756VRN1904VRN1589V | PN0483PN0462W | RN1771RN1765V | PN0463PN0461 | |
| 07.06~ | 3200 | B6324S | AS | RN1904VRN1756VRN1589V | PN0462WPN0483 | RN1771RN1765V | PN0461PN0463 |
| 01.17~ | 1500 | B 4154 T5 | FW | RN1589VRN1904VRN1756V | PN0483PN0462W | RN1765VRN1770 | PN0463 | |
| 07.10~ | 1600 | B 4164 T | FW | RN1756VRN1589V | PN0462WPN0483 | RN1770RN1765V | PN0463 | |
| 01.12~ | 1600 | D 4162 T | FW | RN1756VRN1589V | PN0483PN0462W | RN1765VRN1770 | PN0463 |
| 01.10~ | 2000 | B4204T7 | BW | RN1756VRN1904VRN1589V | PN0483PN0462W | RN1770RN1765VRN1771 | PN0461PN0463 | |
| 01.09~ | 2500 | B5254T10 | BW | RN1589VRN1756VRN1904V | PN0462WPN0483 | RN1771RN1765VRN1770 | PN0463PN0461 | |
| 05.07~ | 3000 | B6304T2 | BW | RN1589VRN1756VRN1904V | PN0462WPN0483 | RN1765VRN1770RN1771 | PN0461PN0463 |
| 10.13~01.17 | 2000 | B4204T11 | 136 | RN1904VRN1589VRN1756V | PN0483PN0462W | RN1770RN1771RN1765V | PN0461PN0463 | |
| 10.13~04.16 | 2000 | D4204T5 | 136 | RN1756VRN1904VRN1589V | PN0462WPN0483 | RN1765VRN1770RN1771 | PN0461PN0463 | |
| 04.10~01.16 | 2000 | D5204T# | 136 | RN1756VRN1904VRN1589V | PN0462WPN0483 | RN1771RN1765VRN1770 | PN0463PN0461 | |
| 06.08~ | 2400 | D5244T4 | 136 | RN1756VRN1904VRN1589V | PN0462WPN0483 | RN1770RN1765VRN1771 | PN0463PN0461 | |
| 03.15~01.17 | 2500 | B5254T | 136 | RN1589VRN1756VRN1904V | PN0483PN0462W | RN1770RN1771RN1765V | PN0463PN0461 | |
| 01.08~01.17 | 3000 | B6304T | T6 | RN1589VRN1756VRN1904V | PN0462WPN0483 | RN1765VRN1771RN1770 | PN0463PN0461 | |
| 08.07~ | 3200 | B6324S | BZ | RN1904VRN1589VRN1756V | PN0462WPN0483 | RN1770RN1771RN1765V | PN0461PN0463 |
