ROTOR DISC » RN1460

Specification

Disc Thickness (Max)
9
Num. of holes
5
Height
59.2
Centering Diameter
64
Front/Rear
Rear
Pitch Circle Ø
114.3
Outter Ø
282
Type
Solid
Drum Ø:
170
Structure Material
G3000
Disc Thickness (Min)
8

Cross Reference

HONDA
42510-S9A-000
HONDA
42510-S9A-N00
HONDA
42510-SCA-E00
HONDA
42510-SMC-N00
HONDA
42510-SMC-N01
HONDA
42510-SMC-N02
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
01.99~07.03 2300 F23A TA1 RN1104V PN8254 RN1460 PN8397 FN0570
09.99~07.03 3000 J30A TA3 RN1104V PN8254 RN1460 PN8397 FN0570
02.00~07.03 3000 J30A TA4 RN1901V PN8465 RN1460 PN8397 FN0570
09.01~08.04 2000 K20A RD4 JPN RN2054V PN8484 RN1460 PN8807 FN0570
08.01~09.04 2000 K20A RD4 LHD PH RN1218V PN8485 RN1460 PN8397 FN0570
09.01~08.04 2000 K20A RD5 JPN RN1177VRN1218VRN2054V PN8484PN8485 RN1460 PN8807 FN0570
11.01~01.05 2000 K20A RD5 RHD RN2054VRN1177V PN8485PN8484 RN1460 PN8397PN8807 FN0570FN8003
11.04~01.05 2000 K20A RD5 RHD RN2054VRN1177V PN8484PN8485 RN1460RN1259 PN8397PN8807 FN0570FN8003
01.04~01.05 2000 K20A4 RD8 RN1218VRN1177V PN8485 RN1259RN1460 PN8807PN8397 FN8003FN0570
09.01~01.05 2400 K24A1 RD6 RN1218V PN8485 RN1460 PN8397 FN0570
09.01~09.04 2400 K24A1 RD7 RN1218V PN8485 RN1460 PN8397 FN0570
02.07~08.10 1800 R18A RT1 RN1540VRN1322V PN8465 RN1460 PN8506 FN0570
02.07~08.10 1800 R18A RT2 RN1322V PN8465 RN1460 PN8506 FN0570
02.07~08.10 2000 R20A RT3 RN1322VRN1218V PN8465 RN1460 PN8506 FN0570
02.07~08.10 2000 R20A RT4 RN1322V PN8465 RN1460 PN8506 FN0570
05.15~07.20 1500 L15B FR5 JPN RN1218V PN8485 RN1460 PN8807 FN0570
02.15~07.20 1500 L15B FR5 RHD RN1218V PN8485 RN1460 PN8807 FN0570
02.15~07.20 1500 LEB-H1 FR4 RN1218V PN8485 RN1460 PN8807 FN0570
05.15~07.20 1800 R18A FR5 RN1218V PN8485 RN1460 PN8807 FN0570
07.06~06.14 1800 R18A RN6 JPN RN1218V PN8465 DN1379RN1460 PN8506FN5524 FN0570
07.06~05.14 1800 R18A RN7 RN1218V PN8465 RN1460 PN8506 FN0570
12.05~01.15 1800 R18A# RN6 RHD RN1218V PN8465 RN1460 FN5524PN8506 FN0570
07.06~05.14 2000 R20A RN8 RN1218V PN8465 RN1460 PN8506 FN0570
07.06~05.14 2000 R20A RN9 RN1218V PN8465 RN1460 PN8506 FN0570

Exemption from liability: the catalog data is advisory and can be used for reference only
