ROTOR DISC » RN2001

RN2001

Specification

Type
Solid
Outter Ø
302
Num. of holes
5
Disc Thickness (Max)
10
Height
31.3
Centering Diameter
76
Pitch Circle Ø
114.3
Disc Thickness (Min)
8.4
Drum Ø:
172
Structure Material
G3000

Cross Reference

HYUNDAI
58411-D3700
HYUNDAI
58411-D7700
KIA
58411-D7700
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

HYUNDAI   »   NEXO

05.18~ 120KW PM518 RN1644V PN0799 RN2001 PN0538

HYUNDAI   »   Tucson

09.20~ 2000 D4HD PTLI20 RN1653V PN0661 RN2001RN1996 PN0591PN0538 FN0697
09.20~ 2000 G4NJ PTLI20 RN1653V PN0661 RN2001RN1996 PN0538PN0591 FN0697

HYUNDAI   »   Tucson 15

04.15~08.18 1600 G4FJ PD315 RHD RN1653V PN0661 RN1996RN2001 PN0591PN0538 FN0697
04.15~08.18 2000 D4HA PD315 RHD RN1653V PN0661 RN2001RN1996 PN0591PN0538 FN0697
04.15~08.18 2000 G4NA PD315 LHD RN1653V PN0661 RN1996RN2001 PN0591PN0538 FN0697
04.15~08.18 2000 G4NA PD315 RHD RN1653V PN0661 RN1996RN2001 PN0591PN0538 FN0757FN0697

HYUNDAI   »   Tucson 16

04.15~08.18 1600 G4FJ PD716 RN1653V PN0578PN0661 RN2001 PN0538 FN0757FN0697
04.15~08.18 1600 G4FJ PD716 EU RHD RN1653V PN0578 RN2001 PN0538
04.15~08.18 2000 G4NA PD716 RUS RN1653V PN0578 RN2001RN1996 PN0436PN0538 FN0757

HYUNDAI   »   Tucson 18

01.18~09.20 1600 D4FE PD718 EU RN1653V PN0578 RN1996RN2001 PN0538PN0436 FN0757
01.18~09.20 1600 G4FJ PD318 RHD RN1653V PN0661 RN2001RN1996 PN0591PN0538 FN0697
08.18~09.20 2000 G4NC PD318 RHD AU RN1653V PN0661 RN2001 PN0538PN0591 FN0697

KIA   »   Sportage

01.19~07.21 1600 D4FE PF119 LHD RN1644VRN1653V PN0578 RN2001RN1996 PN0436PN0538 FN0757
10.15~01.19 1600 G4FJ PF116 RU RN1653V PN0578 RN2001 PN0538 FN0757
05.18~07.21 1600 G4FJ PF119 RHD RN1653V PN0661 RN2001RN1996 PN0591PN0538 FN0697
10.15~11.18 2400 G4KJ PD916 RHD RN1653V PN0661 RN2001 PN0538
