ROTOR DISC » RN2751V

RN2751V

Specification

Type
Vented
Outter Ø
278
Num. of holes
5
Hole Ø:
13.2
Disc Thickness (Max)
23
Disc Thickness (Min)
21
Height
43.9
Centering Diameter
63.6
Pitch Circle Ø
108
Drum Ø:
135.8
Front/Rear
Front
Structure Material
G3000

Cross Reference

FORD
1 751 584
FORD
1 833 857
FORD
1 833 867
FORD
AY11-1125-AA
FORD
AY1Z-1125-A
years Eng Eng No BodyBody Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

FORD   »   B-Max

08.12~09.17 1000 C10FD0X (100PS) CB2 RN2751V PN51010 DN1754 FN0773
08.12~09.17 1000 C10FD0X (120/125PS) CB2 RN2751V PN51010 DN1754 FN0773
08.12~09.17 1400 C14HDEZ (90PS) CB2 RN2751V PN51010 DN1754 FN0773
08.12~09.17 1500 C15DSOX CB2 RN2751V PN51010 DN1754 FN0773
08.12~09.17 1600 C16DSOX (95PS) CB2 RN2751V PN51010 DN1754 FN0773

FORD   »   Fiesta VI

12.12~10.19 1000 C10FD0X VI RN1672VRN2751V PN51010PN5544 RN1018DN1747 FN0806PN0120
12.12~10.19 1000 P4J# (80PS) VI RN1672VRN2751V PN51010PN5544 RN1018DN1747 FN0806PN0120
12.12~10.19 1000 XMJ# (65PS) VI RN1672VRN2751V PN5544PN51010 RN1018DN1747 PN0120FN0806
09.08~10.19 1250 SNJ# (82PS) VI RN2751VRN1672V PN5544PN51010 RN1018DN1747 PN0120FN0806
09.08~10.19 1250 STJ# (60PS) VI RN1672VRN2751V PN51010PN5544 DN1747RN1018 PN0120FN0806
09.08~10.19 1400 F6J# (68PS) VI RN1672VRN2751V PN5544PN51010 RN1018DN1747 PN0120FN0806
07.10~10.19 1400 F6J# (70PS) VI RN1672VRN2751V PN5544PN51010 DN1747RN1018 PN0120FN0806
01.09~10.19 1400 RTJ# VI RN1672VRN2751V PN0876PN51010PN5544 DN1747RN1018 PN0120FN0806
01.13~10.19 1400 RTJ# VI RN1672VRN2751V PN51010PN0876 RN1018DN1747 PN0120FN0806
09.12~10.19 1500 75PS VI RN2751VRN1672V PN51010PN5544 RN1018DN1747 FN0806PN0120
01.13~01.18 1500 Duratec Ti-VCT (110PS) - Sigma B299 MCA RN2751VRN1672V PN51010PN0876 DN1747RN1018 PN0120FN0806
05.15~10.19 1500 XVJ# (95PS) VI RN2751VRN1672V PN51010PN5544 DN1747RN1018 FN0806PN0120
09.08~04.10 1600 HHJ# (90PS) VI RN2751VRN1672V PN51010PN5544 DN1747RN1018 FN0806PN0120
09.08~10.19 1600 HHJF (75PS) VI RN1672VRN2751V PN5544PN51010 RN1018DN1747 PN0120FN0806
09.08~01.13 1600 HXJ# (120PS) VI TI RN1672VRN2751V PN5544PN51010 RN1018DN1747 PN0120FN0806
02.13~10.19 1600 JTJ# (182PS) VI ST RN2751VRN1672V PN51010PN5544 DN1747RN1018 FN0806PN0120
05.16~10.19 1600 JTJC (200PS) VI ST RN1672VRN2751V PN5544PN51010 RN1018DN1747 PN0120FN0806
04.10~10.19 1600 T3JA (95PS) VI RN2751VRN1672V PN51010PN5544 RN1018DN1747 FN0806PN0120
12.10~10.19 1600 U5JA (134PS) VI RN2751VRN1672V PN51010PN5544 DN1747RN1018 FN0806PN0120

FORD   »   Tourneo Courier

04.14~10.23 1500 C15DSOX C4A RN2751V PN51010 DN1754 FN0773

FORD   »   Transit Courier

01.14~05.18 1500 C15DSOX VAN RN2751V PN51010 DN1754 FN0773
