ROTOR DISC » RN2782V

RN2782V

Specification

Type
Vented
Outter Ø
325
Num. of holes
5
Disc Thickness (Max)
28
Disc Thickness (Min)
25
Height
49.2
Centering Diameter
62
Pitch Circle Ø
114.3
Front/Rear
Front
Structure Material
G3000

Cross Reference

TOYOTA
43512-F4061
years Eng Eng No BodyBody Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

TOYOTA   »   C-HR

01.24~ 2000 M20 MAXH21 RN2782V PN1879 RN2753 PN1864
10.23~ 2000 M20 MAXH25 RN2782V PN1879 RN2753 PN1864
