ROTOR DISC » RN2794V

RN2794V

Specification

Type
Vented
Outter Ø
293
Num. of holes
5
Disc Thickness (Max)
26
Height
39.5
Centering Diameter
65
Front/Rear
Front
Structure Material
G3000
Hole Ø:
15.8
Disc Thickness (Min)
24
Pitch Circle Ø
100
Drum Ø:
143.5

Cross Reference

FAW
3501111BK01
years Eng Eng No BodyBody Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

FAW   »   Bestune T77

01.19~ 1200 CA4GA12TD BGE2063 RN2794V PN8010 RN2795 PN0538
03.20~ 1500 CA4GB15TD-30 T77 RN2794V PN8010 RN2795 PN0538
