ROTOR DISC » RN2800

RN2800

Specification

Type
Solid
Outter Ø
273
Num. of holes
5
Disc Thickness (Max)
9.5
Height
36.2
Centering Diameter
69
Pitch Circle Ø
110
Drum Ø:
141
Front/Rear
Rear
Structure Material
G3000
Hole Ø:
13.6
Disc Thickness (Min)
7.5

Cross Reference

CHANGAN
3502101-BN02
CHANGAN
C211F260303-0201
years Eng Eng No BodyBody Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

CHANGAN   »   Eado Plus

03.20~ 1400 JL473ZQ3 SC7145 RN2660V PN0373 RN2800 PN8813
03.21~ 1400 JL473ZQ9 SC7145 RN2660V PN0373 RN2800 PN6030PN8813
04.25~ 1500 JL473QK SC7150 RN2660V PN0373 RN2800
03.20~ 1600 JL478QEP SC7145 RN2660V PN0373 RN2800 PN8813
