NiBK Brakes:: Application Cross Reference and Image for NiBK : ROTOR DISC : RN2804V

Product
Application

ROTOR DISC » RN2804V

Specification

Type

Vented

Outter Ø

319

Num. of holes

6

Hole Ø:

14.5

Disc Thickness (Max)

28

Disc Thickness (Min)

25

Height

67.4

Centering Diameter

108

Pitch Circle Ø

139.7

Drum Ø:

108

Front/Rear

Front

Structure Material

G3000

Alternative

Cross Reference

HI-Q

SD4030

HI-Q

SD4044

HI-Q

SD4098

TOYOTA

43512-04050

TOYOTA

43512-04051

TOYOTA

43512-04052

TOYOTA

43512-0K230

TOYOTA

43512-0K270

TOYOTA

43512-0K280

TOYOTA

43512-0K330

TOYOTA

43512-35320

TOYOTA

43512-35321

TOYOTA

43512-35322

years	Eng	Eng No	BodyBody	Front Rotor	Front Brake	Rear Rotor	Rear Brake	Parking Shoe

TOYOTA » Hilux

08.25~

2800

1GD-FTV

GUN226R

RN2804V RN1446V

PN1482

DN1102

FN0620
