ROTOR DISC » RN2805V
Specification
Type
Vented
Outter Ø
262
Num. of holes
4
Hole Ø:
12.7
Disc Thickness (Max)
21
Disc Thickness (Min)
19
Height
44.7
Centering Diameter
61
Pitch Circle Ø
100
Drum Ø:
124
Front/Rear
Front
Structure Material
G3000
Cross Reference
HONDA
45251-T5G-H00
HONDA
45251-T9A-T00
HONDA
45251-TZR-H00
| years | Eng | Eng No | BodyBody | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 10.19~ | 1500 | L15# | GN2 LHD KX MAK# | RN2805V | PN8868 | DN1389 | FN28002 | |
| 10.19~ | 1500 | L15# | GN2 LHD KY MAK# | RN2805V | PN8868 | DN1389 | FN28002 | |
| 10.19~ | 1500 | L15# | GN2 RHD KU MRH# | RN2805V | PN8868 | DN1389 | FN28002 | |
| 10.19~ | 1500 | L15# | GN2 RHD MA PMH# | RN2805V | PN8868 | DN1389 | FN28002 | |
| 07.23~ | 1500 | L15# | GN2 RHD MA PMH# | RN2805V | DN1389 | FN28002 | ||
| 10.19~ | 1500 | L15# | GN2 VTN | RN2805V | PN8868 | DN1389 | FN28002 | |
| 11.20~07.23 | 1500 | L15# | GN5 LHD PH MRH# HB | RN2805V | PN8868 | DN1389 | FN28002 | |
| 11.20~07.23 | 1500 | L15# | GN5 RHD MA PMH# HB | RN2805V | PN8868 | DN1389 | FN28002 | |
| 12.16~09.20 | 1500 | L15A | GM6 | RN2805V | PN8868 | DN1389 | FN28002 | |
| 01.14~01.17 | 1500 | L15Z1 | GM6 LHD | RN2805V | PN8868 | DN1389 | FN28002 | |
| 01.14~01.17 | 1500 | L15Z1 | GM6 RHD | RN2805V | PN8868 | DN1389 | FN28002 | |
| 12.16~09.20 | 1500 | L15Z1 | GM6 RHD | RN2805V | PN8868 | DN1389 | FN28002 | |
| 12.16~09.20 | 1500 | L15Z1/A7 | GM6 LHD | RN2805V | PN8868 | DN1389 | FN28002 |
| 01.14~02.20 | 1500 | L15Z2 | GK5 GR | RN2805V | PN8868 | DN1389 | FN28002 | |
| 06.17~01.22 | 1500 | L15Z2 | GK5 GR PMH | RN2805V | PN8868 | DN1389 | FN28002 | |
| 01.15~ | 1500 | LEB-H1 | GP# | RN2805V | PN8868 | FN28002 |
