ROTOR DISC » RN2878V

RN2878V

Specification

Type
Vented
Outter Ø
340
Num. of holes
5
Hole Ø:
15
Disc Thickness (Max)
28
Disc Thickness (Min)
26
Height
51
Centering Diameter
67
Pitch Circle Ø
114.3
Drum Ø:
160
Front/Rear
Front
Structure Material
G3000

Cross Reference

HAVAL
3501011XKU00A
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

HAVAL   »   H7

04.16~12.23 2000 GW4C20 RN2878V PN6012PN6048 RN2879V PN6077PN8813
