ROTOR DISC » RN1015

Specification

Type
Solid
Disc Thickness (Max)
10
Num. of holes
5
Height
59
Centering Diameter
68
Front/Rear
Rear
Pitch Circle Ø
112
Outter Ø
245
Drum Ø:
136
Disc Thickness (Min)
8

Cross Reference

AUDI
437615601
BENDIX
561247B
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
08.91~07.93 2200 AAN 4A5 PN0138W RN1015 PN0017
08.91~07.94 2500 AAT 4A2 RN1050V PN0300W RN1015 PN0017
08.91~07.94 2500 AAT 4A5 RN1050V PN0300W RN1015 PN0017
08.91~07.94 2500 ABP 4A2 RN1050V PN0300W RN1015 PN0017
08.91~07.94 2500 ABP 4A5 RN1050V PN0300W RN1015 PN0017

Exemption from liability: the catalog data is advisory and can be used for reference only
