ROTOR DISC » RN1262V
Specification
Type
Vented
Disc Thickness (Max)
24
Num. of holes
5
Height
56
Centering Diameter
110
Pitch Circle Ø
136
Front/Rear
Front
Outter Ø
288
Drum Ø:
162
Disc Thickness (Min)
22
Structure Material
G3000
Cross Reference
MITSUBISHI
MB334308
| years | Eng | Eng No | Body | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 10.93~04.99 | 2800 | 4M40 | FB511A | RN1262V | PN3346 | FN6655 | FN6600 | |
| 04.04~03.07 | 3000 | 4M42 | FE70BB | RN1262V | PN3514 | FN6602 | FN4466 | |
| 04.04~11.14 | 3000 | 4M42 | FE70BS | RN1262V | PN3514 | FN6602 | FN4466 | |
| 04.04~07.11 | 3000 | 4M42 | FE74B | RN1262V | PN3572 | FN6602 | FN0655 | |
| 12.06~05.11 | 3000 | 4M42 | FE82B | RN1262V | PN3514PN3572 | FN6602 | ||
| 02.07~03.13 | 3000 | 4M42 | FE83B | RN1262VDN1881 | PN3514FN6653PN3513 | DN1881 | FN6602FN6653BL1060 | FN4466 |
| 10.89~05.97 | 3600 | 4D32A | FE335EV | RN1262V | PN3349FN6653 | FN6602BL1060 | FN6600 | |
| 10.93~05.99 | 3600 | 4D36 | FE516B | RN1262V | PN3349FN6653 | BL1060FN6602 | ||
| 10.93~05.99 | 3600 | 4D36 | FE516BC | RN1262V | PN3349FN6653 | FN6602BL1060 | ||
| 10.93~05.99 | 3900 | 4D34-T | FE639 | RN1262V | PN3349 | FN6602 | ||
| 04.92~11.93 | 4200 | 4D33 | FE337EV | RN1262V | PN3349 | FN6602 | FN6681 | |
| 10.93~05.99 | 4200 | 4D33 | FE517BD | RN1262V | PN3349 | FN6602 | ||
| 10.93~04.99 | 4200 | 4D33 | FE537 | RN1262V | PN3407FN6653PN3349 | FN6653FN6602BL1060 | ||
| 05.02~08.04 | 4200 | 4D33 | FE71C | RN1262V | PN3514 | FN6602 | ||
| 05.02~12.04 | 4200 | 4D33 | FE72C | RN1262V | PN3514 | FN6602 | ||
| 11.93~05.99 | 4600 | 4D35 | FE638 | RN1262V | FN6653PN3407PN3349 | FN6653FN6602BL1060 | ||
| 01.06~12.10 | 4900 | 4M50 | FE82D | RN1262V | PN3572 | FN6602 | FN0655 | |
| 02.04~05.09 | 4900 | 4M50-T | FE72D | RN1262VRN1451V | PN3514PN3513 | DN1881 | BL1060FN6602FN6653 | |
| 03.02~11.14 | 4900 | 4M50-T | FE82DE | RN1262V | PN3514PN3572PN3571PN3513 | PN3514FN6602BL1060PN3513FN6653 | FN4466 | |
| 05.99~05.02 | 5200 | 4M51 | FE53EC | RN1262V | PN3349 | FN6602 | ||
| 05.99~05.02 | 5200 | 4M51 | FE53EEV | RN1262V | PN3349 | FN6602 | ||
| 05.02~08.04 | 5200 | 4M51 | FE72E | RN1262V | PN3513PN3514 | BL1060FN6653FN6602 | ||
| 05.02~12.04 | 5200 | 4M51 | FE83E | RN1262V | PN3513BL1070 | BL1070 |
