ROTOR DISC » RN1296V

RN1296V

Specification

Type
Vented
Disc Thickness (Max)
19
Num. of holes
4
Height
47
Centering Diameter
64
Front/Rear
Front
Pitch Circle Ø
114.3
Outter Ø
250
Drum Ø:
136
Disc Thickness (Min)
16.5
Structure Material
G3000
Hole Ø:
13.1

Cross Reference

BENDIX EUR
561599B
SUZUKI
55311-60B40
SUZUKI
55311-60B41
SUZUKI
55311-60B42
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

SUZUKI   »   Swift

03.89~05.01 1300 G13B# AA34S RN1296V PN2367 PN8076FN9933
01.89~10.96 1600 G16B SF416 RN1296V PN2367PN9810PN9169 DN1419 FN0032
