ROTOR DISC » RN1474V

RN1474V

Specification

Type
Vented
Disc Thickness (Max)
16
Num. of holes
8
Height
41.2
Centering Diameter
55.5
Front/Rear
Rear
Outter Ø
263
Disc Thickness (Min)
14.5
Pitch Circle Ø
100
Drum Ø:
129

Cross Reference

TOYOTA
42431-17050
TOYOTA
42431-17080
TOYOTA
42431-17081
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

TOYOTA   »   MR-S

01.99~01.07 1800 1ZZ-FE ZZW30 RN1144V PN1472 RN1474V PN1276

TOYOTA   »   MR2

01.00~09.05 1800 1ZZ-FE ZZW30 PN1472 RN1474V PN1276
