ROTOR DISC » RN1479V

Specification

Type
Vented
Disc Thickness (Max)
35
Num. of holes
5
Height
101
Centering Diameter
126
Front/Rear
Front
Pitch Circle Ø
167
Outter Ø
296
Hole Ø:
M14*1.5
Disc Thickness (Min)
32
Drum Ø:
132
Structure Material
G3000

Cross Reference

TOYOTA
43512-36170
TOYOTA
43512-36171
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
08.84~08.88 2400 22R RB26V RN1479V FN2294PN1388 FN2295 FN2298
08.07~12.16 2700 2TR-FE TRB50L RN1479VRN1480V PN1330PN1388 DN1217 BL2329FN2329 FN2320
01.17~ 2700 2TR-FE TRB60 RN1479VRN1480V PN1388PN1330BL2329FN2329 FN2329 FN2298
01.17~ 2700 2TR-FE TRB70 RN1479VRN1480V PN1330PN1388BL2329FN2329 FN2329 FN2298
01.93~07.99 3400 3B BB40 RN1479VDN1226 PN1388 BL2329FN2329 FN2298
08.04~12.16 4000 N04C XZB50 RN1479V PN1330 FN2329BL2329
01.93~08.06 4100 15B-FTE BB50L RN1479V PN1330PN1388 FN2329BL2329 FN2320
01.93~08.06 4100 15B-FTE BB50R RN1479V FN2329PN1330PN1388 BL2329FN2329 FN2320
01.93~08.08 4200 1H-Z HZB40 RN1480VRN1479V PN1388PN1330 BL2329FN2329 FN2298
01.93~01.05 4200 1H-Z HZB50L RN1479V FN2329PN1388 FN2329BL2329 FN2320
01.93~12.16 4200 1H-Z HZB50R RN1479VDN1226 PN1362PN1388 DN1217 FN2329BL2329 FN2320
01.17~ 4200 1H-Z HZB60R RN1480VRN1479V PN1330FN2329PN1388BL2329 DN1217 FN2329 FN2320
01.17~ 4200 1H-Z HZB70L RN1479VRN1480V BL2329PN1388PN1330FN2329 DN1217 FN2329 FN2320

Exemption from liability: the catalog data is advisory and can be used for reference only
