ROTOR DISC » RN1484V

RN1484V

Specification

Type
Vented
Disc Thickness (Max)
22
Num. of holes
4
Height
49.2
Centering Diameter
55
Pitch Circle Ø
100
Outter Ø
237.8
Drum Ø:
127
Disc Thickness (Min)
20
Structure Material
G3000
Front/Rear
Front

Cross Reference

TOYOTA
43512-20530
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

TOYOTA   »   Caldina

11.92~11.02 1500 5E-FE ET196V RN1484V PN1077 FN2285
11.92~05.98 2000 2C CT196V RN1484V PN1077 FN2285
11.92~05.98 2000 2C CT198V RN1484V PN1077 FN2313
08.99~06.02 2000 3S-FE ST198V RN1484V PN1077 FN2313
05.98~06.02 2200 3C-E CT197V RN1484V PN1077 FN2285
05.98~06.02 2200 3C-E CT199V RN1484V PN1077 FN2313

TOYOTA   »   Carina

08.92~08.96 1500 5A-FE AT192 RN1484VRN1058V PN1077PN1322 DN1249DN1244 FN2285
08.96~08.01 1500 5A-FE AT212 RN1058VRN1484V PN1322PN1077 DN1249DN1244 FN2311
