DRUM BRAKE » DN1376

DN1376

Specification

Outter Ø
239
Num. of holes
5
Centering Diameter
64
Height
59.7
Pitch Circle Ø
114.3
Drum Ø
200
Structure Material
G3000
Hole Ø
12.6

Cross Reference

HONDA
42610-S2H-000
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

HONDA   »   HR-V

09.98~10.03 1600 D16A GH1 JPN RN1104V PN8254 DN1376 FN5520
09.98~12.05 1600 D16A GH2 RN1104V PN8254 DN1376 FN5520
09.98~08.01 1600 D16W# GH2 3DR LHD RN1104V PN8254 DN1376 FN5520
09.98~08.01 1600 D16W# GH2 3DR RHD RN1104V PN8254 DN1376 FN5520
