DRUM BRAKE » DN1400

Specification

Outter Ø
296
Num. of holes
5
Hole Ø
14.7
Centering Diameter
72.1
Height
78
Pitch Circle Ø
114.3
Drum Ø
254
Structure Material
G3000

Cross Reference

MAZDA
LC6Y-26-251C
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
05.99~04.02 2000 FS AELV03 EL RN1098V PN5376 DN1400 FN3402
03.02~01.06 2000 RF LW RN1098V PN5376 DN1400 PN5807FN3402
06.99~01.06 2500 GY-DE LW RN1098V PN3813 DN1400 FN3402
05.99~03.02 2500 GY-DE LW5W RN1098V PN3813 DN1400 FN3402
03.02~05.06 3000 AJ LW RN1518V PN5376PN3813 DN1400 FN3402PN5290
03.02~02.06 3000 AJ LWFW RN1098V PN3813PN5376 DN1400 FN3402PN5807

Exemption from liability: the catalog data is advisory and can be used for reference only
