DRUM BRAKE » DN1460

DN1460

Specification

Outter Ø
244
Num. of holes
4
Centering Diameter
62.5
Height
52.9
Drum Ø
203.2
Structure Material
G3000
Hole Ø
12.6
Pitch Circle Ø
100

Cross Reference

HYUNDAI / KIA
58411-G6000
KIA
58411-G6000
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

KIA   »   Picanto

06.20~ 1000 G3LA PG620 RHD RN2435VRN2159V PN0766PN0767 DN1460 FN0746
05.20~ 1000 G3LD PG620 ER RN2159V PN0767 DN1460 FN0746
06.20~ 1200 G4LA PG620 RHD RN2159V PN0767 DN1460 FN0746

KIA   »   Picanto 17

04.17~01.21 1000 G3LA PG617 LHD RN2159V PN0767 DN1460 FN0746PN0768
01.17~02.21 1000 G3LA PG617 RHD RN2159V PN0767 DN1460 FN0746
04.17~01.21 1200 G4LA JA RN2159VRN2435V PN0767PN0766 DN1460 PN0768FN0746
