DRUM BRAKE » DN1473

DN1473

Specification

Outter Ø
249
Num. of holes
4
Hole Ø
12.8
Centering Diameter
43,1
Height
64
Pitch Circle Ø
100
Drum Ø
203.2
Structure Material
G3000

Cross Reference

BENDIX
PDR0781
HYUNDAI
58411-25200
HYUNDAI / KIA
58411-25201
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

HYUNDAI   »   Accent

09.99~06.06 1300 G4EA CG 5DR HB RHD RN1221V PN0091 DN1471DN1473 FN11189FN11909
09.99~06.06 1300 G4EA CG SDN LHD RN1221V PN0091 DN1471DN1473 FN11189FN11909
09.99~06.06 1300 G4EA HB LHD RN1221V PN0091 DN1473DN1471 FN11909FN11189
01.00~06.06 1300 G4EH LC RN1221V PN0091 DN1473DN1471 FN11909FN11189
09.99~10.02 1500 G4#K CG RN1027V PN0091 DN1471DN1473 FN11909FN11189
09.99~06.06 1500 G4EB CH RHD RN1221V PN0091 DN1473DN1471 FN11189FN11909
09.99~01.07 1500 G4EB CH41 LHD RN1221V PN0091 DN1473 FN11189
03.01~08.12 1500 G4EB LC (RUS) RN1221V PN0091 DN1473DN1471 FN11909FN11189
04.01~01.12 1500 G4EC-G LC (RUS) RN1221V PN0091 DN1471DN1473 FN11189FN11909
01.00~06.06 1600 G4ED LC RN1221V PN0091 DN1473DN1471 FN11909PN0436FN0617

HYUNDAI   »   Verna

01.99~06.06 1300 G4EA CG41 RN1221V PN0091 DN1471DN1473 FN11189FN11909
01.00~06.06 1600 G4ED LC RN1221V PN0091 DN1473DN1471 FN11909FN0617PN0436
