DRUM BRAKE » DN1502

Specification

Outter Ø
336
Num. of holes
5
Hole Ø
13.1
Centering Diameter
71
Height
84.6
Pitch Circle Ø
114.3
Drum Ø
295
Structure Material
G3000

Cross Reference

BENDIX
PDR0831
HYUNDAI / KIA
0K58A26251-DS
KIA
0K58A26251
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
01.98~01.05 2500 K5 UP75 PN0602 DN1502 FN0581
12.02~01.06 2900 J3 FL PN0671PN0602 DN1502 FN0581

Exemption from liability: the catalog data is advisory and can be used for reference only
