DRUM BRAKE » DN1513

Specification

Outter Ø

221.5

Num. of holes

4

Centering Diameter

62.5

Height

60.1

Pitch Circle Ø

100

Drum Ø

180

Structure Material

G3000

Hole Ø

12.6

Cross Reference

HYUNDAI

58411-02501

years	Eng	Eng No	Body	Front Rotor	Front Brake	Rear Rotor	Rear Brake	Parking Shoe

HYUNDAI » Atos

12.06~01.11	1000	G4HC	PRIME RHD		PN0439	DN1513	FN11162
01.03~	1100	G4HD	MX		PN0439	DN1513	FN11162

HYUNDAI » Santro

01.99~01.06	1000	G4HC	5 DR SEDAN			DN1513	FN11162
01.98~10.14	1100	G4HG	5 DR SEDAN		PN0439	DN1513	FN11162
