DRUM BRAKE » DN1741

DN1741

Specification

Outter Ø
314
Num. of holes
6
Hole Ø
12.2
Centering Diameter
93.5
Height
89.8
Pitch Circle Ø
139.7
Drum Ø
270
Structure Material
G3000

Cross Reference

ASIA MOTORS
HR236152
ASIA MOTORS
HR236352
ASIA MOTORS
ZR236351
HYUNDAI / KIA
HR236351
HYUNDAI / KIA
HR236352
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

HYUNDAI   »   Galloper

03.97~12.03 2500 D4BH (4D56) KPE1CP RN1335V PN0665 DN1741 FN0595
03.97~12.03 3000 G6AT M10PA01 RN1335V PN0665 DN1741 FN0595
