ROTOR DISC » RN2188V

Specification

Type
Vented
Outter Ø
256
Num. of holes
4
Disc Thickness (Max)
18
Disc Thickness (Min)
16
Centering Diameter
65
Pitch Circle Ø
100
Drum Ø:
132
Structure Material
G3000
Hole Ø:
14
Height
33.9
Front/Rear
Front

Cross Reference

VAG
5U0 615 301 C
VAG
JZZ 698 302 C
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
04.11~05.13 1600 CCRA 5U RN2188VRN2189V PN33017PN33010 DN1538 FN0554
10.09~ 1600 CFZA 5U__F4 RN2188V PN33010 DN1538 FN0554
02.03~03.06 1800 BJY 5X9_F4 RN2189VRN2188V PN0830 DN1522 FN0534
06.02~03.06 2000 UQG 5X97G4 RN2188VRN2189V PN0830 DN1522 FN0534

Exemption from liability: the catalog data is advisory and can be used for reference only
