NiBK Brakes:: Application Cross Reference and Image for NiBK : ROTOR DISC : RN2216V

ROTOR DISC » RN2216V

Specification

Type

Vented

Outter Ø

321

Num. of holes

5

Disc Thickness (Max)

30

Disc Thickness (Min)

27

Height

61

Centering Diameter

70.7

Pitch Circle Ø

115

Drum Ø:

160

Front/Rear

Front

Structure Material

G3000

Cross Reference

CADILLAC (GM)

13585030

GM

23118091

years	Eng	Eng No	Body	Front Rotor	Front Brake	Rear Rotor	Rear Brake	Parking Shoe

CADILLAC (GM) » ATS

02.13~12.18	2000	LTG	6AC69	RN2216V	PN0150S	RN2217V	PN0718	FN0784
02.13~12.18	2500	LCV	6AB69	RN2216V	PN0150S	RN2217V	PN0718	FN0784
02.13~12.18	3600	LFX	6AB69	RN2216V	PN0150S	RN2217V	PN0718	FN0784
