ROTOR DISC » RN2273V

Specification

Type
Vented
Outter Ø
320
Num. of holes
5
Hole Ø:
12.6
Disc Thickness (Max)
28
Disc Thickness (Min)
26.4
Height
45.8
Centering Diameter
69
Pitch Circle Ø
114.3
Drum Ø:
145
Front/Rear
Front
Structure Material
G3000

Cross Reference

MITSUBISHI
4615A230
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
10.17~ 1500 4B40 GK1W RN2273VRN1209V PN3816PN3813 RN1567 PN3815PN3814
12.20~ 2400 4B12 GL3W RN2273V PN3813 RN1567 PN3815

Exemption from liability: the catalog data is advisory and can be used for reference only
