ROTOR DISC » RN2278H

Specification

Type
Solid
Outter Ø
244
Num. of holes
4
Hole Ø:
M12x1.25
Disc Thickness (Max)
9
Disc Thickness (Min)
7
Height
69.3
Centering Diameter
61.9-65
Pitch Circle Ø
108
Front/Rear
Rear
Structure Material
G3000

Cross Reference

GM
39181957
OPEL
39181957
Peugeot / Citroen
16 238 351 80
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
01.17~ 1200 EB2DT A88 RN1151V PN0706 RN2278H PN0019W
01.17~ 1600 DV6FD A88 RN1152V PN0182 RN2278H PN0019W
01.14~ 1200 EB2DT 5-Hatchback RN1152V PN0182 RN2278HRN1747H PN0019W
03.17~ 1200 B12XHL D75 RN1151V PN0706 RN2278H PN0019W
03.17~ 1200 B12XHT P17 RN1151V PN0706 RN2278H PN0019W
03.17~ 1500 D15DT P17 RN1152V RN2278H PN0019W
02.16~ 1600 EP6FDT M CU RN1151V PN0706 RN1747HRN2278H PN0019W

Exemption from liability: the catalog data is advisory and can be used for reference only
