ROTOR DISC » RN2308V

Specification

Type
Vented
Outter Ø
325
Num. of holes
5
Hole Ø:
12.5
Disc Thickness (Max)
20
Disc Thickness (Min)
18
Height
35
Centering Diameter
69
Pitch Circle Ø
114.3
Drum Ø:
160
Front/Rear
Rear
Structure Material
G3000

Cross Reference

HYUNDAI / KIA
58411-P2700
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
06.20~ 2500 G4KM KEURPS120 RN2317VRN2305V PN6135 RN2308V PN6130
01.20~ 1600 G4FT PHC20 RHD RN2305V PN6135 RN2308V PN6130
07.19~ 2200 D4HE PGZ20 LHD RN2317VRN2305V PN6135 RN2308V PN6130
02.20~ 2200 D4HE PGZ20 RHD RN2317VRN2305V PN6135 RN2308V PN6130
04.19~ 2500 G4KM PGZ20 RN2305VRN2317V PN6135 RN2308V PN6130
01.20~ 3500 G6DU PGZ20 RN2305VRN2317V PN6135 RN2308V PN6130

Exemption from liability: the catalog data is advisory and can be used for reference only
