ROTOR DISC » RN25001

Specification

Type
Solid
Outter Ø
302
Num. of holes
5
Disc Thickness (Max)
11
Height
40.8
Centering Diameter
72
Pitch Circle Ø
114.3
Front/Rear
Rear
Disc Thickness (Min)
9
Drum Ø:
152
Structure Material
G3000

Cross Reference

MAZDA
C23Y26251A
MAZDA
C26Y-26-251
MAZDA
C26Y-26-251A
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
07.08~05.13 2000 LF-VD CCEAW RN1194V PN0365 RN25001 PN2702
07.08~05.13 2000 LF-VD CCEFW RN1194V PN0365 RN25001 PN2702
06.09~05.13 2000 LF-VDS CCEFW RN1194V PN0365 RN25001 PN2702
05.13~03.18 2000 PE-VPS CC1071 RHD RN1194V PN0365 RN25001 PN2702
05.13~03.18 2000 PE-VPS CCFFW JPN RN1194V PN0365 RN25001 PN2702
07.08~05.13 2300 L3-VE CC3FW RN1194V PN0365 RN25001 PN2702
06.10~08.17 1600 Y6 CW RN1194VRN1193V PN0365 RN25001RN1373 PN2702
06.10~08.17 1800 L8 CW RN1193VRN1194V PN0365 RN25001RN1373 PN2702
02.05~10.10 1800 L823 CR RN1193VRN1194V PN0365 RN25001RN1373 PN2702
06.10~08.17 2000 LF-VE CW RN1194VRN1193V PN0365 RN25001RN1373 PN2702
06.10~08.17 2000 LF5H CW RN1194VRN1193V PN0365 RN1373RN25001 PN2702
02.05~06.10 2000 LFF7 CR RN1194VRN1193V PN0365 RN25001RN1373 PN2702
02.05~06.10 2000 LFF7 CR19 EU LHD RN1193VRN1194V PN0365 RN25001RN1373 PN2702
10.10~08.17 2000 PE-VPS CW RN1193VRN1194V PN0365 RN25001RN1373 PN2702
02.05~06.10 2000 RF7J CR RN1193VRN1194V PN0365 RN1373RN25001 PN2702
03.08~10.10 2300 L3-V# AUCV02 US RN1193VRN1194V PN0365 RN25001 PN2702
09.04~03.08 2300 L3-VE CR RN1194VRN1193V PN0365 RN1373RN25001 PN2702
06.10~08.17 2500 L5-VE CW RN1194V PN0365 RN25001 PN2702
02.05~07.10 2000 FS7# CR19 RN1194V PN0365 RN25001 PN2702
12.04~08.07 2300 L3-VE CR3W RN1194VRN1193V PN0365 RN1369RN25001 PN2702
08.07~07.10 2300 L3-VE CR3W RN1194V PN0365 RN25001 PN2702

Exemption from liability: the catalog data is advisory and can be used for reference only
