ROTOR DISC » RN2378
Specification
Type
Solid
Outter Ø
288
Num. of holes
5
Hole Ø:
14.1
Disc Thickness (Max)
12
Disc Thickness (Min)
10
Height
46
Centering Diameter
70.7
Pitch Circle Ø
115
Drum Ø:
156.2
Front/Rear
Rear
Structure Material
G3000
Cross Reference
GM
0 986 T16 058
GM
13513886
GM
13517854
GM
13517857
GM
13517858
GM
13521008
GM
13544245
GM
13549949
GM
13583682
GM
13583685
OPEL
13521008
| years | Eng | Eng No | Body | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 07.24~ | 1500 | LSD | 1P#26 | RN2377VRN2612V | PN52011 | RN2378 | ||
| 09.22~06.24 | 1500 | LSD | 1X#26 | RN2377V | PN52015 | RN2378 | PN52022 | |
| 04.17~08.22 | 1500 | LYX | 1X#26 | RN2377V | PN0628PN0674 | RN2378 | PN52022PN0886 | |
| 04.17~08.19 | 1600 | LH7 | 1X#26 | RN2377V | PN0628PN0674 | RN2378 | PN0886 |
| 02.19~ | 1300 | L3T | 1ZR69 | RN2377V | PN52015 | RN2378 | PN52022 | |
| 04.18~ | 1500 | LFV | 1Z#69 KR | RN2377V | PN0674 | RN2378 | PN52022PN0886 | |
| 09.15~04.18 | 1500 | LFV | 1ZA69 KR | RN2377V | PN0674PN0628 | RN2378 | PN52022PN0961PN0886 | |
| 04.15~04.18 | 1500 | LFV | 1ZD69 US | RN2377V | PN0628PN0674 | RN2378 | PN0961 | |
| 04.18~ | 1500 | LFV | 1ZD69 US | RN2377V | PN52015PN0674PN0628 | RN2378 | PN52022PN0961 | |
| 04.18~ | 1500 | LFV | ZA5C GCC | RN2377V | PN52015PN0628 | RN2378 | PN52022PN0886 | |
| 01.16~12.19 | 1800 | LKN | 1ZE69 | RN2377V | PN0674 | RN2378 | PN0961 | |
| 04.15~03.18 | 2000 | LTG | 1FZ69 US | RN2377V | PN0674PN0628 | RN2378 | PN0886 | |
| 04.15~03.18 | 2000 | LTG | 1Z#69 GCC | RN2377V | PN0628PN0674 | RN2378 | PN52022PN0886 | |
| 01.16~ | 2500 | LCV | 1ZX69 | RN2377V | PN0628PN0674 | RN2378 | PN0886 |
| 10.24~ | 1500 | LSD | TP#26 | RN2612VRN2377V | PN52011 | RN2378 | ||
| 09.22~09.24 | 1500 | LSD | TX#26 | RN2377V | PN52015 | RN2378 | PN52022 | |
| 01.17~08.22 | 1500 | LYX | TX#26 | RN2377V | PN52015PN0674 | RN2378 | PN0886PN52022 | |
| 01.17~09.20 | 2000 | LTG | TX#26 | RN2612V | PN0674PN0694 | RN2378 | PN0886 |
| 03.20~09.22 | 1200 | D12XHT (LES) (EB2ADTS) | Z18 | RN34003V | RN2378 | PN0886 | ||
| 03.17~ | 1500 | B15SFT | T68 ZT6 HB | RN34003V | PN0887PN0694PN34002PN0713 | RN2378 | PN52014PN0886 | |
| 03.17~ | 1600 | B16DTH / D16DTH / LVL | Z18 | RN2612V | PN0694PN0887 | RN2378 | PN0886 | |
| 03.17~03.20 | 2000 | D20DTH | Z18 | RN2612V | PN0694 | RN2378 | PN0886 | |
| 11.20~04.22 | 2000 | F20DVH | Z18 | RN2612V | PN52011 | RN2378 | PN0886PN0712 |
