ROTOR DISC » RN1624V

Specification

Type
Vented
Outter Ø
320
Num. of holes
6
Disc Thickness (Max)
26
Height
42.9
Centering Diameter
82.3
Pitch Circle Ø
139.7
Front/Rear
Front
Disc Thickness (Min)
24.4
Drum Ø:
185
Structure Material
G3000

Cross Reference

NISSAN
40206-7S000
NISSAN
40206-ZC00A
NISSAN
40206-ZC00B
NISSAN
40206-ZC01A
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
01.04~08.05 5600 VK56DE JA60 RN2095VRN1624VRN1430V PN0841PN0428 RN1431 PN0429 FN0639
08.03~03.07 5600 VK56DE TA60 GL GCC RN1624V PN0428 RN1431 PN0429 FN0639
10.03~02.07 5600 VK56DE A60 RN1624V PN0428 RN1431 PN0429 FN0639

Exemption from liability: the catalog data is advisory and can be used for reference only
