ROTOR DISC » RN1638V

Specification

Type
Vented
Outter Ø
363
Num. of holes
12
Disc Thickness (Max)
42
Height
100.2
Centering Diameter
110
Pitch Circle Ø
136.7
Front/Rear
Front
Hole Ø:
12.2
Disc Thickness (Min)
39
Drum Ø:
176
Structure Material
G3000

Cross Reference

BENDIX
PRT5558
GM
97182771
GM
98006395
ISUZU
8-97182-771-0
ISUZU
8-98006-395-0
ISUZU
8-98006-395-1
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
07.08~01.19 5200 4HK1-TCC NQR75 RN1638V PN4803BL1032 FN4401 FN4466
01.08~10.17 5200 4HK1-TCN NQR75 RN1638V FN4401PN4803BL1032 FN4401 FN4443FN4466
10.07~ 5200 4HK1-TCN N_R75U RN1638V FN4401BL1032PN4803 FN4401 FN4443FN4466

Exemption from liability: the catalog data is advisory and can be used for reference only
