DRUM BRAKE » DN1115

Specification

Outter Ø
329
Num. of holes
6
Centering Diameter
69
Height
80.7
Pitch Circle Ø
139.7
Drum Ø
270
Structure Material
G3000

Cross Reference

TOYOTA
42431-26100
TOYOTA
42431-26180
TOYOTA
42431-26181
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
08.95~04.98 2700 3RZ-FE RCH11W RN1266V PN1237PN1516 RN1605VDN1115 PN1363FN2330 FN0567
07.99~05.02 3400 5VZ-FE VCH22K RN1266V PN1237PN1516 DN1115 FN2330
08.95~08.01 2400 2L-T LXH12L RN1266V PN1516PN1237 DN1115 FN2330
08.95~08.01 2400 2RZ-E LXH12R RN1266V PN1237PN1516 DN1115 FN2330
08.95~08.01 2400 2RZ-E RCH12L RN1266V PN1237PN1516 DN1115 FN2330
08.01~11.11 2500 2KD-FTV KLH12R RN1266V PN1237PN1516 DN1115 FN2330
08.01~11.11 2500 2KD-FTV KLH22R RN1266V PN1237PN1516 DN1115 FN2330
04.98~08.04 2700 3RZ-FE RCH13L RN1266V PN1237 DN1115 FN2330
06.97~05.02 2000 3RZ-FE RCH42V RN1266V PN1516PN1237 DN1115 FN2330
04.97~08.04 3000 5L-E LXH43V RN1266V PN1237PN1516 DN1115 FN2330

Exemption from liability: the catalog data is advisory and can be used for reference only
