ROTOR DISC » RN1790VSET

Specification

Type
Vented
Outter Ø
304
Num. of holes
5
Disc Thickness (Max)
30
Height
47.5
Centering Diameter
67
Pitch Circle Ø
112
Front/Rear
Front
Drum Ø:
154
Disc Thickness (Min)
27.4
Structure Material
G3000

Cross Reference

MERCEDES-BENZ
A 211 421 12 12
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
07.03~07.09 2600 M 112.917 S211 RN1790VSET PN0166 RN1271 PN0344W FN0657
03.02~12.08 2600 M 112.917 W211 RN1790VSET PN0166 RN1271 PN0344W FN0657
03.05~07.09 3000 OM 642.921 S211 RN1790VSET PN0500PN0166PN0102 RN1272V PN0344W FN0657
03.05~07.09 3000 OM 642.921 S211 RN1790VSET PN0166PN0102PN0500 RN1272V PN0344W FN0657
07.03~01.05 3200 M 112.954 S211 RN1790VSET PN0166 RN1272V PN0344W FN0657
03.05~07.09 3500 M 272.972 S211 RN1790VSET PN0102PN0500PN0166 RN1272V PN0344W FN0657

Exemption from liability: the catalog data is advisory and can be used for reference only
